Specifications
Racing Components – Entire Range
The tried and tested suspension package and the special components of Beta’s race-ready version are confirmed:
ø 48 mm Kayaba AOS close cartridge fork: anodised internal parts and the treatments administered to the materials minimise sliding friction, while adjustable compression and rebound damping let each rider find the perfect customisation of the setting.
Kayaba C46 RCU Monoshock: the KYB Monoshock can be considered a benchmark in the racing context for its capacity to absorb the roughness of the terrain, the level of traction transferred to the vehicle, and the consistency of performance, even in particularly heavy use. Its hydraulic setting can be fully customised by adjusting the external compression (both high and low speed) and rebound settings.
Quick release front axle: immediately recognisable by the red anodised alloy release lever, this component is crucial for saving precious seconds in a race when you need to change a tyre.
Reinforced handguards: the handguards feature a two-component material mould, and not only give the bike a racing look but also make them especially hard-wearing in even the roughest off-road use.
Ergal alloy footpegs: to ensure maximum control at all times and no loss of contact with the bike, the RR Race models are fitted with Ergal racing footpegs with steel pins which are interchangeable; these are narrower than in the past to facilitate movement of feet, but better in terms of grip.
Rear sprocket with anodised aluminium core and steel toothing by ZF SPROCKETS: top-class performance, lightness and strength – the perfect mix of all the attributes any racing component must have.
Dedicated race seat: with non-slip upholstery and document holder pocket for unparalleled grip, comfort and practicality.
Racing graphics: to never go unnoticed on the race field.
Anodised black gear lever and rear brake pedal.
Gearbox oil filler cap, engine oil filler cap and oil filter cap anodised red aluminium.
Chain tensioners in red Ergal alloy.
On all two-stroke models, Beta has decided to stick with its choice of doing away with an automatic mixer (available in the Factory Parts catalogue) in order to minimise the weight of the bike.
RR Race 4Str
4-stroke engines received new maps with respect to the previous Model Year, to improve their delivery along the entire range. Whatever the displacement, Beta engineers optimized their linearity and usability of the propellers, to better manage the power available, at any speed, even on complex terrains.
| Frame | Molybdenum steel with double cradle split above the exhaust port |
| Wheelbase | 1480 mm |
| Max length | 2180 mm |
| Max width | 830 mm |
| Max height | 1275 mm |
| Seat height | 950 mm |
| Ground clearance | 335 mm |
| Footrest height | 427 mm |
| Dry weight | 107,5 kg (front 52,7 kg; rear 54,8 kg) |
| Fuel tank capacity | 9,0 l. |
| Reserve | 2,3l. |
| Cooling system capacity | 1,4 l. |
| Front suspension | Hydraulic USD fork with ø48 mm shaft |
| Rear suspension | Monoshock with progressive compound lever |
| Shock absorber stroke | 130 mm |
| Front wheel travel | 300 mm |
| Rear wheel travel | 287 mm |
| Front brake | Wave disc ø260 mm and double-piston floating caliper |
| Rear brake | Wave disc ø240 mm and single-piston floating caliper |
| Front rim | 21 x 1,6 – 36 holes |
| Rear rim | 18 x 2,15 – 36 holes |
| Front tyre | 90/90 – 21 |
| Rear tyre | 140/80 -18 |
| Type | Single cylinder, 4-stroke, liquid-cooled |
| Bore | 88 mm |
| Stroke | 63,4 mm |
| Displacement | 385,6 cc |
| Compression ratio | 12,48:1 |
| Valve train | DOHC finger follower / 4 titanium valve |
| Starter | Electric starter |
| ACG | Kokusan |
| Spark plug | NGK LKAR 8A-9 |
| Lubrication | 2 oil pumps |
| Fuel system | Elldor dual electronic injection |
| Throttle body | Ø 42 mm – Synerject |
| Clutch | wet multi-disc clutch |
| Primary drive | Z. 28/76 |
| Transmission | 6 gears |
| Final transmission | chain |
| Engine oil | SAE 10W/50 0,8 l. + SAE 10W/40 0,8 l. |
| Consumption | 3,3 l/100 km |
| Pollution | Co2 [g/km] 79 |
