Specifications
Frame – Molybdenum steel with double cradle split above the exhaust port
Wheelbase – 1477 mm
Max length – 2167 mm
Max width – 830 mm
Max height – 1270 mm
Seat height – 930 mm
Ground clearance – 325 mm
Footrest height – 410 mm
Dry weight – 97,0kg (front 47,0 kg; rear 50,0 kg)
Fuel tank capacity – 9,5 l.
Reserve – 2,3 l.
Cooling system capacity – 1,3 l.
Front suspension – Hydraulic USD fork with ø 48 mm shaft
Rear suspension – Monoshock with progressive compound lever
Shock absorber stroke – 132 mm
Front wheel travel – 295 mm
Rear wheel travel – 290 mm
Front brake – Wave disc ø260 mm and double-piston floating calliper
Rear brake – Wave disc ø240 mm and single-piston floating calliper
Front rim – 21 x 1,6 – 36 fori
Rear rim – 18 x 1,85 – 36 fori
Front tyre – 90/90 – 21
Rear tyre – 140/80 -18
Type – Single cylinder, 2-stroke, liquid-cooled
Bore – 62 mm
Stroke – 63 mm
Displacement – 190.2 cc
Compression ratio – 13,65:1
Exhaust Valve – BPV system
Starter – Electric starter
Ignition – AC Kokusan – digital CDI
Spark plug – NGK BR8ECM
Induction system – induction reed
Lubrication – Mixing with electrical pump
Carburettor – Keihin PWK 36
Clutch – wet multi-disc with reverse opening
Primary drive – Z.23/73
Transmission – 6 gears
Final transmission – chain
Engine oil – SAE 10W/40
Consumption l/100 km – 2,5
Pollution Co2 [g/km] – 59
