Specifications
Frame – Molybdenum steel with double cradle split above the exhaust port
Wheelbase – 1482 mm
Max length – 2175 mm
Max width – 830 mm
Max height – 1270 mm
Seat height – 930 mm
Ground clearance – 320 mm
Footrest height – 407 mm
Dry weight – 103,5 kg (front 50,8 kg; rear 52,7 kg)
Fuel tank capacity – 9,5 l.
Reserve – 2,3l.
Cooling system capacity – 1,3 l.
Front suspension – Hydraulic USD fork with ø 48 mm shaft
Rear suspension – Monoshock with progressive compound lever
Shock absorber stroke – 132 mm
Front wheel travel – 295 mm
Rear wheel travel – 290 mm
Front brake – Wave disc ø260 mm and double-piston floating calliper
Rear brake – Wave disc ø240 mm and single-piston floating calliper
Front rim – 21 x 1,6 – 36 holes
Rear rim – 18 x 2,15 – 36 holes
Front tyre – 90/90 – 21
Rear tyre – 140/80 -18
Type – Single cylinder, 2-stroke, liquid-cooled
Bore – 67,4 mm
Stroke – 69,9 mm
Displacement – 249 cc
Compression ratio – 13,2:1
Exhaust Valve – BPV Systsem
Starter – Electric starter
Ignition – AC Kokusan – digital CDI with oil pump controller
Spark plug – NGK BR8ECM
Induction system – induction reed
Lubrication – Mixing with electrical pump
Carburettor – Keihin PWK 36
Clutch – wet multi-disc clutch
Primary drive – Z.27/72
Transmission – 6 gears
Final transmission – chain
Engine oil – SAE 10W/40
Consumption l/100 km – 2,2
Pollution Co2 [g/km] – 53
