Engine
Bore × Stroke (mm) – 66 x 43.8
Carburation – 32mm Keihin FCR flat slide carburettor with throttle position sensor (TPS)
Compression Ratio – 11.7:1
Engine Displacement (cc) – 149.7
Engine Type – Liquid-Cooled 4-Stroke 4-Valve Unicam Single
Starter – Kick
Wheels
Brakes – F: 220mm hydraulic disc with single-piston calliper and sintered metal pads, R: 190mm hydraulic disc with single piston calliper and sintered metal pads
Suspension Front – 37mm inverted Showa leading-axle telescopic fork with adjustable compression and rebound damping; 275mm axle travel
Suspension Rear – Pro-Link with single Showa damper, adjustable compression and rebound damping; 282mm axle travel
Tyres – F: 70/100-19, R: 90/100-16
Wheels – Aluminium rim/wire spoke
Dimensions and Weights
Caster Angle – 27°
Dimensions (L×W×H) (mm) – 1,900 x 770 x 1,171
Frame type – Semi-double; Steel tube
Fuel Tank Capacity (Litres) – 4.3 litres
Ground Clearance (mm) – 336
Kerb Weight (kg) – 84.4
Seat Height (mm) – 866
Trail (mm) – 96
Weight (kg) – 84.4
Wheelbase (mm) – 1285
