Engine
Bore × Stroke (mm) – 78 × 54.2
Carburation – PGM FI electronic fuel injection
Compression Ratio – 10,5 : 1
Engine Displacement (cc) – 258.9 cm3
Engine Type – Single cylinder, 4 strokes, 4 valves, SOHC, liquid cooling
Starter – Kick
Throttle Bore – 28 mm
Oil Capacity (Litres) – Engine: 0.6 litres, Transmission: 0.57 litres
Wheels
Brakes – F: Hydraulic disc 185 x 3.5 mm with 4 piston monobloc calliper and sintered metal pads, R: Hydraulic disc 183 × 3.5 mm dual-piston calliper
Suspension Front – Telescopic fork TECH 39mm, adjustable in preload and extension. 190mm travel.
Suspension Rear – Pro-Link with damper R16V system, adjustable for pre-load, extension. 170mm travel
Tyres – F: 80/100 21 (Dunlop), R: 120/100 R18 (Dunlop)
Wheels – F: 21 × 1,60, R: 18 × 2,15
Dimensions and Weights
Caster Angle – 23°
Dimensions (L×W×H) (mm) – 2,035 x 835 x 1,160 mm
Frame type – Aluminium Twin Tube
Fuel Tank Capacity (Litres) – 4.3 litres
Ground Clearance (mm) – 325 mm
Seat Height (mm) – 905 mm
Weight (kg) – 82 kg
Wheelbase (mm) – 1,335 mm
